A dedicated 100-250g butter packaging machine precisely controls the freshness of every portion.
This custom-designed packaging process addresses butter's tendency to stick and its need for temperature control. The 100-250g weight range offers an accuracy of ±1g, eliminating spillage and waste.
Equipped with a constant-temperature conveying system, it preserves the butter's delicate flavor. Its sealing technology prevents moisture and oxidation, extending its shelf life.
This fully automated machine offers high efficiency and compatibility with a variety of packaging films. Whether it's small-sized household items or commercial sizes, it can quickly complete packaging, ensuring efficient market launch of butter products.
Model No. | MTW-BW500 |
Machinetype | rotarytype,continuousoperation | Outerreeldiameter,mm | upto400 |
Standard size | 200g butter brisk size: 100*75*25mm | Material thickness, mm | 0.05-0.08 |
250g butter brisk size: 100*75*30mm | Control | PLC and HMl with Touch Screen |
450g butter butter brisk size: 150*75*45mm | Accuracy, g | 9-15g-1g:20-25g-1,5g |
500g butter brisk size 150*75*55mm | Productivity regulation | incrementally |
Applicable products | butter, margarine | Lubrication system | central (optional) |
Max capacity.packs/min | up to 40 | Washing mode | manual |
Dose mass,g | 200-500 | Compressed air supply, Pa (bar) | 0,4-0,8Mpa; 4-8Bar |
Product input temeprature.'C | butter+10....+14;margarine +8....+14 | Compressed air consumption, | 500L/min |
Feeding | hopper with 2 horizontal augers or direct feeding | Voltage, V | 230V |
Dosing type | volumetric | Frequency, Hz | 50/60 |
Packaging material | laminated aluminum foil | Electricity supply | 3 phase |
Folding type of package | bottom folding | Approx. machine size (LxVxH), mm | 2800x2600x1700 |
Inner reel (core) diameter, mm | 70 or 75 | Approx.machine weight, kg | 1900 |
